About Aarav Pharma Chem

Aarav Pharma Chem

Aarav Pharma Chem, one of the fastest growing companies engaged in the business of research, manufacturing and marketing of Flora Coat ready-mix film coating system for the pharmaceuticals, neutraceuticals, veterinary, herbal & ayurvedic Industry. We are committed to on time supply and consistent quality.


We, manufacture ready to use film coating material for solid oral dosage forms for Normal Film Coating, Functional Coating & speciality Products.


We have our head office at Ahmedabad ? one of the most important industrial center in the western part of India.

Our Product

Aarav Pharma chem manufactures and supplies the full range of film coating material under the brand name of Flora Coat, for regular film coating and functional coating. Flora Coat has wide range of products available. Depending upon the requirement, the customer can take help of our expert advice for choosing the right product for their application.
Our Products:
  • Aqueous system: Flora Coat AFC
  • Solvent System: Flora Coat NFC

Example for tablet Batch Size: 100 Kg
Product Usage Use level Based
Flora Coat AFC Ready mix material for film coating with aqueous system 1.5-2.5% HPMC
Flora Coat NFC Ready mix material for film coating with Non-aqueous (Solvent) system 1.5-2.5% HPMC

Solvent
Product Description Recon. Level Flora Coat Req. Water IPA MDC
Flora Coat AFC Aqueous 16% 2.0 kg 18.0 kg
Flora Coat NFC Solvent 5% 2.0 kg 15.2 kg 22.8 kg
* Depends on coating facilities at customer’s premises and product to be coated
** Flora Coat AFC Flora Coat NFC Conventional Auto Coater Conventional Auto Coater
Flora Coat AFC Flora Coat NFC
Conventional Auto Coater Conventional Auto Coater
Coating Equip. 36" 46" 36" 48"
Solvent system Aqueous Aqueous Organic Organic
Pan Speed(rpm) 8-12 3-5 8-12 3-5
Baffles 4-6 6-8 4-6 6-8
Tablet charge(kg) 40-50 100-130 40-50 100-130
Bed Temp. 38-42c 38-42c 35-40c 35-40c
Spray nozzle 1.2mm 1.2-1.5mm 1.2mm 1.2-1.5mm
No. spray gun 1 2-3 1 2-3
Air Pressure 3-3.5 bar 3-3.5 bar 2.5-3.5 bar 2.5-3.5 bar
spary procedure Continue Continue Continue Continue
Spray Rate(gm/min) 50-60 120-140 100-150 300-400
Intel air temp 65-75c 65-75c 60-65c 60-65c
Drying air volume(cfm) 400-500 15000-2000 400-500 15000-2000
Weight gain% 1.75-2.0 1.8-2.0 1.75-2.0 1.75-2.0
Flora Coat has wide range of products for enteric coating system suitable for various pharmaceutical solid oral dosage forms (Tablets, drug loaded pellets, herbal granules, Ayurvedic and Neutraceuticals) for protection in gastric medium. Flora Coat is also available for use in aqueous enteric coating for soft gel capsules and targeted colonic delivery.
Our Products:
  • Aqueous system: Flora Coat E Aq. (based on Methacrylic Acid co-polymer type “c”)
  • Solvent System: Flora Coat EN (based on Methacrylic Acid co-polymer type “c”)
  • Flora Coat REC (based on Cellulose acetate Phthalate)

Product Usage Use level Based
Flora Coat EN Ready mix material for Enteric coating with Solvent system 6.0-7.0% Methacrylic Acid co- polymer Type “A”
Flora Coat RE C Ready mix material for Enteric coating with Solvent system 7.0-9.0% Cellulose Acetate Phthalate
Flora Coat E Aq. Ready mix material for Enteric coating with Aqueous system 8.0-9.0% Methacrylic Acid co- polymer Type “C”

Flora Coat E Aq. Is Methacrylic acid copolymer type “c” based ready mix powder. Flora Coat E Aq. Film is insoluble in gastric fluids and natural juice but freely soluble in intestinal track at pH 5.5 and above by formation of soluble salts of electrolytes present in GI tracks. Example for tablet Batch Size: 100 Kg
Solvent
Product Description Recon. Level Flora Coat Req. Water IPA MDC
Flora Coat E Aq. Aqueous 12-15% 9.0 kg 66-51 kg
Flora Coat EN Solvent 10% 7.0 kg 1/2 63.0 Kg/ 44.0 Kg + 19.0 kg Acetone
Flora Coat REC Solvent 5% 8.0 kg 112.0 kg 28.0 kg
* Depends on coating facilities at customer’s premises and product to be coated
** Flora Coat AFC Flora Coat NFC Conventional Auto Coater Conventional Auto Coater
Flora Coat E Aq. Flora Coat EN Flora Coat REC
Conventional Auto Coater Conventional Auto Coater Conventional Auto Coater
Coating Equip. 36" 48" 36" 48" 36" 48"
Solvent system Aqueous Aqueous Organic Organic Organic Organic
Pan Speed(rpm) 8-12 3-5 8-12 3-5 8-12 3-5
Baffles 4-6 6-8 4-6 6-8 4-6 6-8
Tablet charge(kg) 40-50 100-130 40-50 100-130 40-50 100-130
Bed Temp. 35-40c 35-40c 30-35c 30-35c 38-40c 38-40c
Spray nozzle 1.2mm 1.2-1.5mm 1.2mm 1.2-1.5mm 1.2mm 1.2-1.5mm
No. spray gun 1 2-3 1 2-3 1 2-3
Air Pressure 2-2.5 bar 2-2.5 bar 1.5-2.5 bar 1.5-2.5 bar 2.5-3.5 bar 2.5-3.5 bar
spary procedure Continue Continue Continue Continue Continue Continue
Spray Rate(gm/min) 50-60 120-150 60-75 200-300 100-140 300-350
Intel air temp 65-75c 65-75c 45-50c 45-50c 60-65c 60-65c
Drying air volume(cfm) 400-500 15000-2000 400-500 15000-2000 400-500 15000-2000
Weight gain% 8.0-9.0 8.0-9.0 6.75-7.0 6.75-7.0 7.5-8.0 7.5-8.0
Aarva Pharma Chem has developed products for excellent moisture barrier coating for moisture sensitive drugs. Flora Coat MFC provides good stability and protection for hygroscopic drugs.
Product Usage Use level Based
Flora Coat MFC Ready mix material for Moisture Barrier coating for Moisture sensitive Product 3.0-4.0% HPMC+ Ethyl cellulose

Flora Coat MFC
Weight Gain 3.0-4.0%
Addition of colorants Ready to use
Reconstitution level 5.0% organic {IPA- 40% + MDC- 60%}
Application:
  • Ayurvedic, Herbal & Unani Drugs
  • Amitriptyline HCl, Atorvastatin
  • Ethambutol
  • Multivitamin, Ranitidine HCl, all Hygroscopic Drugs

Coating Suspension Preparation

Flora Coat systems are very easy to prepare. Add the Flora Coat powder in solvent/water as described below and mix for 45 minutes with propeller stirrer.

Equipment:
  • S.S. Vessel with a capacity of 25% more than total suspension being prepared. The height of the vessel should be around 1.25times than its diameter.
  • A variable speed propeller stirrer with blade diameter of nearly 1/3 of the diameter of S.S. Vessel as described above.

Procedure for Mixing:
1. Aqueous system:
  • Weigh the required quantity of Flora C oat.
  • Take required quantity of water in vessel.
  • Stir with propeller stirrer to form vortex. Add quantity of Flora Coat in vortex, stir for 5 min.
  • Reduce the speed of stirrer and continue for 40 minutes.
  • Pass the solution through 150micron opening sieve & use for coating.
2. Solvent/ Non Aqueous system:
  • Weight the required quantity of Flora Coat.
  • Take required quantity of IPAC in vessel.
  • Stir with propeller stirrer to form vortex. Add quantity of Flora Coat in vortex, stir for 5 min.
  • Add quantity of Methylene Dichloride and continue for 40 minutes.
  • Pass the solution through 150micron opening sieve & use for coating.
Precautions:
  • The usage of high speed stirrer or homogenizer is not recommended.
  • The suspension should not be passed through colloidal mill for Flora Coat E Aq.
  • The suspension may need gentle stirring during the coating operation to maintain its homogeneous property during spray.
  • The suspension thus prepared should be used within 24 hours to avoid any microbial contamination.

Trouble Shooting

Excessive Drying Time:
  • Check Dilution
  • Check drying air temperature (optimum Temp. 500-600C.)
  • Check spray rate. Reduce spray rate if necessary
  • Check automizing air pressure. If automizing air pressure is less than 80 psi, larger drops are formed resulting in increased drying time and surface roughness.
Excessive Flying of coating material:
  • Check side air flow. Excessive side air flow will cause premature drying of spray, resulting in flying of coating material particles.
  • Check distance of spray gun from tablet bed surface. Take gun slightly closer to the tablet bed.
  • Check drying air temperature. Higher drying air temperature will cause premature drying of spray causing deposition of particles on the tablet surface.
  • Check side air flow. If side air flow is high then there is a chance of coating material drying up before reaching tablet surface. The dried particles can cause roughness on tablet by sticking to its surface.
  • High viscous solution can also give rough surface by creating hindrance in proper spraying. Check dilution.
Roughness on tablet surface:
  • Check friability of core tablets.
  • Check distance of surface gun from tablet bed surface. Do not keep the gun very close to the bed surface or very far away from it. A distance of 9”- 12” will be ideal.
  • Check drying air temp at optimum level mentioned above.
  • Increase spray rate if necessary. Excessive fine spray can also cause premature drying of spray.
  • Check atomizing air pressure. Very high atomization can result in premature drying.
Development of white patches during coating (sticking between tablets):
  • Check spray rate. Reduce spray rate is necessary
  • Check whether coating pan surface has got excessive coating solution on it. If excessive coating solution is present on pan surface then this film gets wet causing sticking of tablets to the pan surface. On drying, the material peels off from tablet surface resulting in white patches. In such cases, clear pan surface and then continue coating.
  • Check side air flow and dilution.
  • Ensure good rolling of tablets in the pan. Improper rolling or sliding of tablets in the pan can cause excessive rubbing of tablets at the bottom of the bed and also excessive wetting of tablets on the top. This can also cause development of patches.
Uneven distribution of colour from tablet to tablet:
  • This is due to inefficient rolling of the tablets in the pan. To get uniform distributions of colour ensure good rolling of tablets in the pan. Use additional baffle if necessary.
  • Spreading of the solution spray by opening the side air flow will aid in improving.
